PULSAtron Series E-DC Pumps, 12-Volt DC Pumps
Perfect for field applications with portable generators.
Pulsafeeder's Series E 12-VDC pumps provide the same great features as the E Plus premium line of pumps in a 12-volt DC version. Great for remote locations like wells, lagoons, or resorts where there isn't a permanent power source. These pumps can be used with car batteries or solar panels.
Series E pumps feature an on/off switch and manual speed and stroke controls. UL listed for indoor and outdoor use. The sealed housing provides superior protection from the elements.
Use with: caustic, chiorarnines, hydrochloric acid, potassium permanganate, sodium bisulfate and sodium hypochlorite (call for compatibility with other chemicals)
Wetted materials: PVC head & fittings, PTFE seats and 0-rings, ceramic check balls, PTFE faced diaphragm.
Maximum viscosity: LSO2 & LS13 = 300 cP;1314 &1_5414 =1000 cP
Metering accuracy: ±3%
Tubing size: 3/8" OD
Wetted materials: PVC head & fittings, PTFE seats and 0-rings, ceramic check balls, PTFE faced diaphragm.
Maximum viscosity: LSO2 & LS13 = 300 cP;1314 &1_5414 =1000 cP
Metering accuracy: ±3%
Tubing size: 3/8" OD
Power: 12 VDC, 190 watts max, nominal (11.8 to 14 VDC)
Suction lift: 4 ft dry, 10 ft once primed at 1 cP
Duty cycle: continuous
Suction lift: 4 ft dry, 10 ft once primed at 1 cP
Duty cycle: continuous
Turndown ratio: 100:1
Shipping weight: 10 to 25 lbs
The Pump Models that you can buy from this page are:
- LS02S4-VTC1-XXX, 6 GPD, 150 PSI
- LS14S4-VTC1-XXX, 24 GPD, 100 PSI
- LS44S4-VTC1-XXX, 44 GPD, 100 PSI
NOTE: THIS IS ONLY A SMALL SAMPLING OF E-DC PUMPS. WE WILL WRITE YOU A PDF QUOTATION ON ANY PULSAFEEDER PUMP.
